Specification

StyleSpin-On Filter
Efficiency 15µ @ β200
Efficiency 27µ @ β1000
Outer Diameter 96.0 mm
Length 210.0 mm
Thread1 1/2"-16 UN
MediaGlass Fiber
Δ Collapse Pressure 17 BAR
Seal MaterialNitrile
Temperature Range -30 - +100°C

FilterFinder Approved Product

We Guarantee The FilterFinder FF200129B Is

  • The Same Fit, Form & Function as the Original Pall HC7400SUN8H.
  • Fully Inspected in Accordance with ISO 9001:2015.

What This Means For You

  • Simple No Quibble 45 Day Returns.
  • 1 Year Manufacturer Warranty.
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
5µ @ β200
Efficiency 2 7µ @ β1000
Style Spin-On Filter
Outer Diameter 96.0 mm
Inner Diameter
Length 210.0 mm
Media Type Glass Fiber
Flow Direction
Thread 1 1/2"-16 UN
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure 17 BAR
Seal Nitrile
Temperature Range -30 - +100°C
